ProductstructureImagesensorCameralensThisline-lasersensorintegratesnon-contactsensortechnologyofMitutoyo.LaserdiodeCollimatinglensHigh-accuracycylindricallensCLASS2bluelaserThreeproductfeatures(1)High-accuracyandenvironment-resistantsensorThesensoritselfisguaranteedforaccuracy,inaddition,ithasachievedtheIP67protectionlevel,providingstablemeasurements.(2)SupportingautomatedmeasurementTheSurfaceMeasure-SSeriescanobtainthetwo-dimensionalandthree-dimensionalshapesofmeasurementworkpiecesathighspeed(amaximumframerateof10kHz)andmakeanautomaticjudgmentinsidethesensor.Itisalsoequippedwithapartsmatchingfunctionthatallowsthemeasure-menttooltobeappliedthroughout,regardlessoftheorientationsofthepartsbeingmeasured.Measure-mentscanbetakenwithoutperformingalignment.(3)SimpleoperabilityThesoftwaresupportsintuitiveoperationandisbuiltintothesensor(softwareinstallationisnotrequired),soyoucanuseitimmediatelyaftermounting.6-2
| <
|
> |
>>
