ABSST1300SeriesSystemconfigurationTapescaleDetectorheadFeedbackcableAboutthefeedbackcable•ForthefeedbackcabletoconnecttotheYaskawaElectricCorporation'sservoamplifier,aserialcablefromYaskawaElectricCorporationisavailable.CablemodelNo.:JZSP-CLP70-□□-E(03,05,10,15,20)•ForthefeedbackcabletoconnecttoMitsubishiElectricCorporationMR-J4Series,placeanorderwithMitutoyowiththefollowingCodeNo.specified.FeedbackcableforMR-J4Series,5m:06ACF117A,10m:06ACF117BControldeviceConnectorNote:Thefeedbackcableandcontroldevicearetobeconstructedandconnectedbytheclient.IfthefeedbackcablefromYaskawaElectricCorporationisused,theST1380Aconnectingcable(optional:06AFA434A)isneeded.ItemstobeconstructedbytheclientST1380AConnectioncableCodeNo.06AFA434A06AFA434B06AFA434CCablelength(m)2005001000MeaningofModelNo.ABSST1341A-1200DAbsolutetypeSeriesnameSeparateTypeABSOLUTELinearScaleABSST134ABSST130Interfacespecification0:SupportsMitutoyoENSIShigh-speedserialinterface4:SupportsMitsubishiElectricCorporationhigh-speedserialinterface5:SupportsFANUCCORPORATION,highspeedserialinterface7:SupportsPanasonicCorporation,high-speedserialinterface8:SupportsYaskawaElectricCorporationhigh-speedserialinterfaceABSST135ABSST137AAAABSST138AScalemountD:Double-endedmountingtypeE:Double-sidedtapemountingtypeF:Centermountingtype(Withoutsystemparameters)G:Centermountingtype(Withsystemparameters)Effectiverange:10mmto12000mmTransmissionmethodA:When0,4,7,or8isselectedintheinterfacespecificationlistedontheleftNothing:When5isselectedintheinterfacespecificationlistedontheleftResolution1:Resolution0.01μm2:Resolution0.001μmAvailableInterfacesApplicableinterfaces*FANUCCORPORATION,SerialαiSeriesMitsubishiElectricCorporation,MELSERVOServoAmplifierMR-J4SeriesYaskawaElectricCorporation,SERVOPACKΣ-7SeriesPanasonicCorporation,MINASA5/A6SeriesMitutoyoENSIS*Besuretocontacteachmanufacturerfordetailsoftheapplicablesystems(availabilityofconnection).8-10
| <
|
> |
>>
